Azbil dcp551 mark II User Manual

4 - 8 Auxiliary Output (Output CH1, CH2) Connection
4-10
■ Auxiliary output CH1 connection
■ Auxiliary output CH2 connection
48
+ -
49
4 to 20mAdc
Load resistance less than 600
Ω
Receiver
+ -
Chapter 4. WIRING
50
+ -
51
4 to 20mAdc
Load resistance less than 600Ω
Receiver
+ -
WARNING
Before removing, mounting, or wiring this module, be sure to turn off the
power to the module and all connected devices.
Doing so may result in an electric shock.
