Chapter 9. MEMORY CARD OPERATIONS
■ Auto load using external switch inputs
● Conditions
Memory card : Program saved to file number 1
Setup data : any of C71 to C74 is set to 8 (autoload)
Mode : READY mode, normal display mode
● Operation and action
Insert a memory card and turn off the external switch used for autoload and turn it
back on again.
The DCP551 operates as follows.
•“AUtO ” is displayed in display panel 1 and “LOAd ” is displayed in display
panel 2.
• When program number 1 has been loaded onto the DCP551, program number
1 disappears.
• File number 1 on a memory card is loaded onto the DCP551 as program
number 1.
• When a load operation is successful, the “AUtO ” and “LOAd ” indications go
off and the normal display mode appears.
Unless the number of a program is selected using external switch inputs,
program 1 in segment 1 is selected.
• If the load operation fails, the “AUtO ” and “LOAd ” indications stay on and an
error code is displayed in the message panel.
When an error has occurred, press the DISP key to return to the normal display
mode.
Handling Precautions
Variable parameter PA05 can be set to 1 or 0.
