Azbil dcp551 mark II User Manual

4 - 6 PV Input (Analog Input) Connection
■ PV input CH1 connection
PV input CH1 is a multi-input type input for sensors. Connect as shown below,
according to the type of sensor being used.
■ PV input CH2 connection
PV input CH2 is a multi-input type input for sensors. Connect as shown below,
according to the type of sensor being used.
4-7
T/C
Thermocouple input Resistance temperature detector input
54 55 56
+ -
RTD
54 55 56
ABC
Chapter 4. WIRING
CAUTION
Current applied to current input terminals
(55), (56) and (58), (59)
must meet
the specified range.
Failure to heed this caution may lead to fire or equipment breakdown.
54 55 56
+
-
+ -
54 55 56
- +
- +
Current (mA)
transmitter
DC voltage input
DC current input
T/C
57 58 59
+ -
RTD
57 58 59
ABC
Thermocouple input
Resistance temperature detector input
