9-7
Chapter 9. MEMORY CARD OPERATIONS
Card battery alarm panel
When the voltage of the internal battery in a RAM card is too low, the data saved
on the disk may be corrupted. Loading corrupted data onto the DCP551 will
cause maloperation. Do not use a card whose battery voltage is too low. If you
want to load the data anyway, select “Ignore” in this panel and press the ENTER
key. This displays the load menu. To return to the normal display mode, select
Quit” or press the ENTER key or the DISP key.
Procedures for loading individual programs
This procedure loads single memory card files on the DCP551.
File number selection
Load Program
01 PROG01 ?
Program number selection
ENTER key
Load 01 PROG01
DCP 01 ?
Program delete check
ENTER key
Load 01 PROG01
DCP 01 Delete ?
Load check
ENTER key (Delete)
Load 01 PROG01
DCP 01 LOAD ?
Load complete
LOAD key
Load 01 PROG01
DCP 01 Good
ENTER key
(Displays the tag to right side of the number.)
, , , key
, , , key
(Displayed when there are
programs on the DCP551.)
key (Not delete)
Card battery alarm screen
Battery Alarm
Quit / Ignore ?
ENTER key
(The item indicated by the cursor can be selected.)
“Quit” returns you to the normal display mode.
“Ignore” displays the load menu.
, key
