Chapter 9. MEMORY CARD OPERATIONS
■ Procedures for loading all programs
This procedure loads all programs on the memory card in the DCP551. The file
numbers used on the memory card are converted to file numbers used in the
DCP551.
When the “Overwrite” load function is selected, programs in the DCP551 that
have the same number as those on the card are overwritten by the card programs.
When the “Skip” load function is selected, programs in the DCP551 that have the
same number as those on the card are left as they are and the next number is
selected for processing.
■ Procedures for loading setup data
This procedure loads setup data on the memory card onto the DCP551.
■ Procedures for loading variable parameters
This procedure loads variable parameters on the memory card onto the DCP551.
■ Procedures for loading PID parameters
This procedure loads PID parameters and constant value control data on the
memory card onto the DCP551.
Data delete check
Delete Old Data
LOAD ?
Load completed
LOAD key
PID Data
LOAD Good
DISP key
Normal display mode
(Load operation is not performed.)
DISP key
Normal display mode
Data delete check
Delete Old Data
LOAD ?
Load completed
LOAD key
PARA Data
LOAD Good
DISP key
Normal display mode
(Load operation is not performed.)
DISP key
Normal display mode
Data delete check
Delete Old Data
LOAD ?
Load completed
LOAD key
SETUP Data
LOAD Good
DISP key
Normal display mode
(Load operation is not performed.)
DISP key
Normal mode display
Select load function
Overwrite / Skip
LOAD ?
State of load progress
LOAD key
Load All Prog.
Program 01
Load completed
Load All Prog.
Good
DISP key
Normal mode display
Displays loading program number.
(The item indicated by the cursor can
be selected.)
, key
