1 - 4 System Configuration
1-4
■ CPL communications network-based configuration
Models equipped with the optional communications interface can be connected as
a slaved DigitroniK’s controller to a CPL communications* network. In this case,
the user can employ as the master station a personal computer.
*: CPL(Controller Peripheral Link) Communications network is the host-
communications.
Chapter 1. PRODUCT OUTLINE
PC
PC PC
RS-232C
DCP551
(slave station)
DCP551
(slave station)
ST221DE05DCP (Smart Terminal dedicated display)
(slave station)
RS-485
DCP551 (master station)
RS-232C/RS-485 converter CMC10L001A000
RS-485 (5-wire system)
RS-485 Connection example
RS-485 (3-wire system)
*
* "Communication controller CMC10L001A000" is
RS-232C/RS-485(3-wire system) converter in Azbil corporation.
