3. Getting to know the projector
3.3 Projector components
Projector components
9
1
7
3
4
8
5
2
2
2
6
Image 3-2
Item No. Description
1
IR rece iv e r, front
2
Adjustable feet
3 Projector lens holder
4 Projector exhaust
5
Mains power connector
6
Connector panel
7
IR Receiver, rear
8 Lamp house cover
9 Keypad
18 601–0307–00 F50 25/02/2016
