8. Set up the picture
8.2 Use test images
About
Main Men u — Installation — Test Image
Built-in test imag es can be used to check and refine display aspect and focus on the screen when installing the projector or a new
lens.
Use the arrow keys to navigate to the req uired a spect ratio. T he display w ill cha nge dynamically.
Available test im ages:
•Off
•4:3
• 16:9
• 16:10
• 1.85:1
• 2.35:1
•5:4
• Combined (displays all available aspec t ratios simultaneously)
• F ocus
