6. Input and communication
6.8 VGA
Specifi ca tions
Parameter Valu e
Connector VGA 15 pin female HD-DSUB a nalog RGBH V
Horizontal frequency range
10 - 150kHz
Vertical frequency range
50 - 110Hz
Sync signals Separate horizontal and vertical
Composite sync on H -sync Input
Sync on Green (So G)
Scan format
Interlaced or progressive
Dot (pixe l) clock rate Analog VGA 10 - 162 MHz m ax
Maximum resolution
1920x1200 @ 60H z
Nominal sync impedance
Selectable 75 ohm s or 2k 2 ohms
Input levels
RGBwithsync 1.0Vp-p±2dB(0.35Vpp–1.4Vpp)
