6. Input and communication
6.3 Wireless remote c ontrol
General
The projector has 2 IR receivers, one at the front and one a t the rear, which are used to receive signals from the wireless remote
control.
The wireless remote c ontrol is powe red by two (2) standard A AA batteries. The battery compartment is on the back side of the
remote control (ref. 11, image 6- 2).
Functions
10. Menu
8. Hash key
9. OK
7. Power
6. Source selection
2. Auto settings
1. Info
3. Lens shift
5. Back button
4. Navigation arrows
SOURCE
POWERINFO
SHIFT
MENU
BACK
i
OK
11. Battery cover
Image 6-2
Item No. Name D escription
1
Info Shortcut key to a ctivate the p rojector O SD ’Status’ m enu
2 Auto settings Activates the projector ’A uto’ settings
3
Lens shift Activates Lens Shift function.
4 Navigation arrows
Directional / navigation tolls
5
Back button R eturn to previous menu alternative
6
Source s election Toggles forward and backwards between a
vailable source s
7
Power
Switches the projector lamp and electr
onics ON or O FF
8 Hash key Not in use
9.
OK Confirms t he curren t selection
10. Menu
Shortcut key to activate or deactiv
ate the on screen menu display (OSD)
11. Battery cove r Removable battery compartment cover
Specifi ca tions
Parameter Valu e
Type
IR, NEC p rotocol
Sensors
2
Carrier
38 kHz
Range
7m
Laser 1 m W, 67 0nm
Disable an IR Receiver on the projector
Each of the IR receivers on the projector operates individually of the other, and can be enabled or disabled as required.
To enable or disable the front IR receiver, g o to Main Menu — Installation — IR Front.
To enable or disable the rear IR receiver, go to M ain Menu — Installation — IR Rear.
48
601–0307–00 F50 25/02/2016
