5. Installation
5.2 Installation conditions
General
This section contains important physical and env ironme ntal information that will he lp you determine the optimal installation position
and conditions for your projector.
Barco projectors are m anu factured according to sp ecific design standards, w hich also include en vironmental
conditions. Failing to follow the terms and conditions outlined in this chapter can result in loss of product
warranty.
Environmental conditions
The table b elow summarizes the phy sical environment in which the projector may be safely operated or stored.
Environment Operating Storage
Ambient Temperature @
1500 M
10 °C (50 °F) to 40 °C (104 °F) -15 °C (5 °F) to 60 °C (140 °F)
Ambient Temperature @
3000 M
10 °C (50 °F) to 35 °C (95 °F) -15 °C (5 °F) to 60 °C (140 °F)
Air c leanliness
Clean office environ ment (equivalent with cleanroom
standard ISO 14644-1 ISO Class 9)
n.a.
Relative humidity (R H) 20% to 80% RH Non-condensed 10% to 90% RH Non-condensed
Mains power requirements
Projector Power requirements
F50
100 — 240 V, 50 — 60 Hz, 16 A @ 240 V
To protect opera ting personnel, the National Electrical Manufacturers Association (NEMA) recomm ends that the instrument panel
and cabinet be grounded. In no event shall this projector be operated without an adequate cabinet ground connection.
The AC supply must be installed by a qua lified e lectrician in co nformance to local codes. H ardware, wire sizes and conduit types
must comply with local codes.
Ventilation
The projector is fan cooled and mus t be installed with sufficient space around the projector to ensure sufficient air flow. See image 5 -1
Ventilation inlets are located on the left and right sides of the projector. Hot air is ex hausted from the rear ve nt.
150mm
500mm 500mm
500mm
Image 5-1
Projector weight and footprint
Weight: 7.5 kg (exclusive of lens)
Dimensions show n in millimeters (mm).
601–0307–00 F50 25/02/2016
31
