11. Multichannel installations
11.5 Synchronization menu 3D
3D Source sync
Main menu — Installation — S ynchronization — 3D source sync
Used to define which input sou rce will be used for left eye/right eye synchronization signal.
The m enu options for 3D source sync differ lightly depending on which 3D mode is selected.
See table be low for more information:
Menu
option
Frame sequential mode In side by side mode In dual head mode
Source The s ource will determ ine the order of
the input frames. Accurate only with
DP sources w ith inband s ync. For
other sources this w ill only be correct
50% of the times and the 3D menu
option, Swap eyes, must be used to
correct the problem.
Not available Not available
Sync
1,2,3
Use the signal on the selected sync-in
to determine the order of the input
frames.
Use the signal on the selected
sync-in to determine the order of the
input frames.
Use the signal on the selected
sync-in to determine the order of the
input frames.
3D Display sync
Main menu — Installation — S ynchronization — 3D source sync
Used to define which display source will be used for left eye/right eye synchronization signal.
The m enu options for 3D source sync differ lightly depending on which 3D mode is selected.
See table be low for more information:
Menu
option
Frame sequential m ode In side by side mode In dual head m ode
Source Use the ord er of the input frames
from the source itself. This will only
be correct 50% of the times and the
swap eyes option m ust be used to
correct the problem.
Not available Not available
Sync
1,2,3
Use the signal on the selected
sync-in to determine the order of the
input frames.
Use the signal on the selected
sync-in to determine the order of the
input frames.
Use the signal on the selected
sync-in to determine the order of the
input frames.
3D Sync 1
Main menu — Installation — Synchronization — [3D] Sync 1
This menu option is used to select wh ich signal the Sync 1 connector shall send out.
When a Sync in connector (Sync 1,2,3) is use d for source or display synchronization it will automatically be
configured as ’input’ and it will not be possible to select any type of output for this connector.
Setting
Description
Input
Used as sync signal to determine the order of input frames.
Display
sync
Sends the sync signal from the 3D display sync source.
Glass
sync
Sends a signal that is used to s ynchronize the shutter glasses. Connect this signal to the IR or RF emitter.
Sync 2 Sends the sync signal from the sync 2 connector.
Sync 3 Sends the sync signal from the sync 2 connector.
3D Sync 2
Main menu — Installation — Synchronization — [3D] Sync 2
This menu option is used to select wh ich signal the Sync 1 connector shall send out.
100
601–0307–00 F50 25/02/2016
