5. Installation
5. INSTALLATION
CAUTION: Alw ays rem ove the lens from the lens holder be fore mo ving or transpo rting the projector. Failure
to do this may cause damage to the lens holder and prism.
Overview
Installing the projector
Installation conditions
Initial inspection
Positioning the projector
Mounting the pro jector on a at surface
Installing the projector to a c eiling mount or frame
Throw distance
Lens shift and offset m atrix
Scheimp ug (Boresight) adjustment
Scheimp ug adjustment
601–0307–00 F50 25/02/2016
