Barco F50 User Manual

6. Input and communication
6.6 Extended D isplay Identification D ata (EDID)
Restore source format integrity
Main m enu — Installation — E DID
In s ome instances when using 3rd par ty system equipmen t, s uch as signal repeaters or switchers, EDID (Extended Display Iden-
tification Data) information can be lost or corrupted in translation. Wrong EDID data may result in distorted images, wrong as pect
ratios or reduced image resolutions.
To m anually define the EDID d etailed timing descriptor, go to the EDID su b menu M ain menu — Installation —
EDID.
Connector
Values Auto settings 1080 Auto settings
WUXGA
Auto settings
WQXGA
VGA Auto, 960x 1080@ 60 Hz
2
, 960x 1200@ 60
Hz
2
, 1280x1600@@60 H z
2
,WUXGA,
1080@60 Hz, SX+ , SXGA , 1366x768,
720@60 Hz , 72 0@50 Hz, XG A , SVGA ,
VGA.
1080@60 Hz WUXGA@ 60 Hz W UX GA@ 60 Hz
DVI
Auto, 960x 1080@ 60 Hz
2
, 960x 1200@ 60
Hz
2
, 1280x1600@@60 Hz
2
, WQXGA@60
Hz, WUXGA@ 60 Hz,1080@ 60Hz, SX+,
SXGA, 1366x768, 720@60Hz, 720@50Hz,
XGA, SVGA, VGA.
1920x1200@60 Hz.
Dual link
1920x1200@60 Hz.
Dual link
2560x1600@60 Hz.
Dual link
HDMI
3
Auto, 960x 1080@ 60 Hz
2
, 960x 1200@ 60
Hz
2
, 1280x160 0@@ 60 Hz
2
,
WUXGA@60Hz, 1080 @60Hz, SX+,
SXGA, 1366x768, 720@60Hz, 720@50Hz,
XGA, SVGA, VGA.
1920x1080@60 Hz 1920x1200@60 Hz 2560x1600@60 Hz
HDBaseT
4
Auto, 960x1080@ 60 Hz
2
, 960x1200@ 60
Hz
2
, 1280x1600@@60 Hz/120 Hz
2
,
WUXGA@60Hz, 1080@60Hz, SX+,
SXGA, 1366x768, 720@60Hz, 720@50Hz,
XGA, SVGA, VGA.
1920x1080@60 Hz 1920x1200@60 Hz 2560x1600@60 Hz
Display P ort 1
Auto, 960x1080@60 Hz/120 Hz
2
,
960x1200@60 Hz
2
, 12 80x1600@ @ 60
Hz
2
, WQXG A@ 60Hz, W UX GA@120Hz,
WUXGA@60Hz, 1080@60Hz, SX+,
SXGA, 1366x768, 720@60Hz, 720@50Hz,
XGA, SVGA, VGA.
1920x1080@60 Hz 1920x1200@60 Hz 2560x1600@60 Hz
Display P ort 2
Auto, 960x 1080@ 60 Hz
2
, 960x 120
0@60
Hz
2
, 1280x1600@@60 Hz
2
,
WQXG A @60H z, WU X G A@ 60Hz,
1080@60Hz, S X+, SXGA, 1366x
768,
720@60Hz, 720@50Hz, XGA, SVGA ,
VGA.
1920x1080@60 H z; 1920x1200@60 Hz 2560x1600@ 60 Hz
2. For Picture by Picture use
3. All settings except Auto use DVI as type.
4. All settings except Auto use HDMI as type.
