7. Advanced
6. Use the arrow keys to select the desired check box and press ENTER to activate or deactivate the item.
7.10 Installation
Overview
• Internal Patterns
• Scaled patterns
• Formatter patterns
•LFR
• Convergence
Not all the menu items of the Installation menu are handled in this chapter. The other items are treated in the
Installation or Setup chapter .
7.10.1 Internal Patterns
Overview
The projector is equipped with different internal patterns which can be used for adjustment purposes.
Geometry adjustments can not be used on these internal patterns.
Image 7-175
Outline
Image 7-176
Hatch
Image 7-177
Color bars
Image 7-178
Checkerboard
152 R59770286 NW-12 07/09/2009
