5. Setup
5. SETUP
Overview
• Powering up the projector
• Starting up the projector
• Setting up the RCU address
• Setting up the projector address (only if necessary)
• Setting up the orientation
• Adjusting the lens
• Setup the baud rate for serial communication
• Preferences
• Setup of linked projectors in a multichannel system
5.1 Powering up the projector
How to power up the projector ?
1. Switch the power switch to “1”
Image 5-1
Power switch
2. The software will be initialized. This may take up to 30 seconds. During this phase the LCD display is lit (1). The initialization is
followed by the keypad lighting up briefly (5 seconds) and the projector Standby status (2) .
NW-12 standby
1
2
Image 5-2
Switch ON sequence
