Basler GigE SERIES User Manual

AW00089317000 Standard Features
Basler ace GigE 281
Different degrees of overlap are illustrated in Figure 118. The hatched areas in the figure indicate
areas of overlap.
 If the Auto Function AOI is completely included in the Image AOI (see (a) in Figure 118), the
pixel data from the Auto Function AOI will be used to control the image property.
 If the Image AOI is completely included in the Auto Function AOI (see (b) in Figure 118), only
the pixel data from the Image AOI will be used to control the image property.
 If the Image AOI only partially overlaps the Auto Function AOI (see (c) in Figure 118), only the
pixel data from the area of partial overlap will be used to control the image property.
 If the Auto Function AOI does not overlap the Image AOI (see (d) in Figure 118), the Auto
Function will not or only to a limited degree control the image property. For details, see the
sections below, describing the individual auto functions.
We strongly recommend completely including the Auto Function AOI within the
Image AOI, or, depending on your needs, choosing identical positions and sizes
for Auto Function AOI and Image AOI.
You can use auto functions when also using the reverse X and reverse Y mirroring
features. For information about the behavior and roles of Auto Function AOI and
Image AOI when also using the reverse X or reverse Y mirroring feature, see the
"Mirror Image" (Section 10.11 on page 268).

Basler GigE SERIES Specifications

General

Interface	GigE
Lens Mount	C-Mount, CS-Mount
Sensor	CMOS
Mount	C-mount, CS-mount
Power Supply	Power over Ethernet (PoE)
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	Varies by model
