AW00089317000 I/O Control
Basler ace GigE 71
6 I/O Control
This section describes how to configure the camera’s physical input line and physical output line. It
also provides information about monitoring the state of the input and output lines.
6.1 Configuring the Input Line
6.1.1 Selecting the Input Line as the Source Signal for
a Camera Function
The camera is equipped with one physical input line designated as input line 1.
You can select the camera input line to act as the source signal for one of the following camera
functions:
Acquisition Start Trigger - If the input line is selected as the source signal for the acquisition
start trigger, whenever a proper electrical signal is applied to the line, the camera will recognize
the signal as an acquisition start trigger signal.
Frame Start Trigger - If the input line is selected as the source signal for the frame start trigger,
whenever a proper electrical signal is applied to the line, the camera will recognize the signal
as a frame start trigger signal.
Frame Counter Reset - If the input line is selected as the source signal for the frame counter
reset, whenever a proper electrical signal is applied to the line, the counter value for the frame
counter chunk feature will be reset.
Trigger Input Counter Reset - If the input line is selected as the source signal for the trigger
input counter reset, whenever a proper electrical signal is applied to the line, the counter value
for the trigger reset counter chunk feature will be reset.
For detailed information about selecting input line 1 to act as the source signal for
the acquisition start trigger and for details about how the acquisition start trigger operates, see
Section 7.3 on page 89.
the frame start trigger and for details about how the frame start trigger operates, see
Section 7.4.3 on page 103.
a frame counter reset and for details about how the frame counter chunk feature operates, see
Section 11.3 on page 314.
a trigger input counter reset and for details about how the trigger input counter chunk feature
operates, see Section 11.3 on page 314.
For more information about the electrical characteristics of the input line, see Section 5.7 on
page 63.
By default, input line 1 is selected as the source signal for the frame start trigger.
