9 Pixel Data Formats
By selecting a pixel data format, you determine the format (layout) of the image data transmitted by
the camera. This section provides information about the available pixel data formats.
9.1 Pixel Formats Available on Mono
Cameras
9.2 Pixel Formats Available on Color
Cameras
Depending on the camera model, the cameras equipped with a Bayer pattern color filter can output
color images based on the Bayer pixel formats given in the following tables. The color filter
alignment depends on the camera model (BG, GB, GR, or RG color filter alignment).
Mono Camera
Model
Mono 8 Mono 12 Mono 12
Packed
YUV 4:2:2
Packed
YUV 4:2:2
(YUYV) Packed
All mono camera
models
  
Table 22: Pixel Formats Available on Monochrome Cameras ( • = format available)
Color Camera
Model
Mono 8 Bayer
BG 8
Bayer
BG 12
Bayer
BG 12
Packed
YUV
4:2:2
Packed
YUV 4:2:2
(YUYV)
Packed
acA640-90gc
  
acA640-120gc
acA645-100gc
acA750-30gc

acA780-75gc
  
acA1300-22gc
acA1300-30gc
acA1600-20gc
acA1920-25gc
acA2500-14gc
Table 23: Pixel Formats Available on Color Cameras (
• = format available) - BG Models
