AW00089317000 Standard Features
Basler ace GigE 267
10.10.3 Horizontal Decimation
Valid for: see Table 41 on page 264
The horizontal decimation feature (sub-sampling in horizontal direction) lets you specify the extent
of horizontal sub-sampling of the acquired frame, i.e. you can define pixel columns that you want to
be left out from transmission.
The horizontal decimation feature does not increase the frame rate.
AOI width
If you use the horizontal decimation feature and you reset the decimation
parameter back to 1, i.e. the horizontal decimation feature is deactivated, the AOI
width can be smaller than the maximum possible width (determined by the pixel
resolution in horizontal direction).
In this case you can manually set the AOI width back to the maximum possible
height.
