AW00089317000 Specifications, Requirements, and Precautions
Basler ace GigE 35
1.4.3 Mechanical Stress Test Results
Cameras were submitted to an independent mechanical testing laboratory and subjected to the
stress tests listed below. The mechanical stress tests were performed on selected camera models.
After mechanical testing, the cameras exhibited no detectable physical damage and produced
normal images during standard operational testing.
The mechanical stress tests were performed with a dummy lens connected to a C-mount. The
dummy lens was 35 mm long and had a mass of 66 g. Using a heavier or longer lens requires an
additional support for the lens.
Test Standard Conditions
Vibration
(sinusoidal, each axis)
DIN EN 60068-2-6 10-58 Hz / 1.5 mm_58-500 Hz / 20 g_1 Octave/Minute
10 repetitions
Shock (each axis) DIN EN 60068-2-27 20 g / 11 ms / 10 shocks positive
20 g / 11 ms / 10 shocks negative
Bump (each axis)
DIN EN 60068-2-29 20 g / 11 ms / 100 shocks positive
20 g / 11 ms / 100 shocks negative
Vibration
(broad-band random,
digital control, each axis)
DIN EN 60068-2-64 15-500 Hz / 0.05 PSD (ESS standard profile) / 00:30 h
Table 9: Mechanical Stress Tests
