Basler GigE SERIES User Manual

Standard Features AW00089317000
198 Basler ace GigE
10.1.1 Setting the Gain
The camera’s gain is determined by the value of the Gain Raw parameter. Gain Raw is adjusted on
an integer scale. The minimum setting varies depending on the camera model and on whether
vertical binning is enabled (see Table 27). The maximum setting depends on whether the camera
is set for a pixel data format that yields
 8 bit effective pixel depth (e.g. Mono 8, YUV 4:2:2 Packed, YUV 4:2:2 (YUYV) Packed) or
 an effective pixel depth of 12 bits per pixel (e.g. Mono 12, Mono 12 Packed, Bayer BG 12,
Bayer BG 12 Packed).
All Models
Except
acA1920-25, acA2000-50, acA2040-25, and acA2500-14
.
This section (Section 10.1) describes how gain can be adjusted "manually", i.e.,
by setting the value of the Gain Raw parameter.
The camera also has a Gain Auto function that can automatically adjust the gain.
Manual adjustment of the Gain Raw parameter will only work correctly, if the
Gain Auto function is disabled.
For more information about
 auto functions in general, see Section 10.13 on page 276.
 the Gain Auto function, see Section 10.13.4 on page 284.
Camera Model Min Setting Min Setting with
Vertical Binning
(mono cameras)
Max Setting
(8 bit depth)
Max Setting
(12 bit depth)
acA640-90gm/gc 190 100 1023 400
acA640-120gm/gc 100 100 1023 600
acA645-100gm/gc 200 140 1023 400
acA750-30gm/gc 0 NA 1023 600
acA780-75gm/gc 250 140 1023 400
acA1300-22gm/gc
acA1300-30gm/gc
300 200 850 400
acA1600-20gm/gc 230 220 850 400
Table 27: Minimum and Maximum Allowed Gain Raw Settings
