baxter iLED 7 User Manual

Technical data
7990087_030_03 – 2080492 – 2023-01-19 77
Voltage at the fixed point on the ceiling 48 V
Classification according to the Act on Medical Devices (MPG) 1
Electrical data
Operating mode
Surgical light system Continuous operation
Lighting data
All light technology values maximum +/- 10% tolerance
Central lighting intensity at a distance
of 0.8 m/1.0 m/1.3 m
(31.50 inch/39.37 inch/51.18 inch)
160,000 lux
Dimmable from/to < 10% Endo
30% – 100%
Light field size can be varied by
changing the distance
16 cm – 30 cm / 6.30 inch – 11.81 inch
Focusable light field size
(d10) at 1.0 m/39.37 inch
Narrow Medium Wide
approx.
16 cm/
6.30 inch
approx.
20 cm/
7.87 inch
approx.
25 cm/
9.84 inch
Focusable light field size
(d50) at 1.0 m/39.37 inch
Narrow Medium Wide
approx.
10 cm/
3.94 inch
*1
approx.
12 cm/
4.72 inch
*1
approx.
14 cm/
5.51 inch
*1
*1
The value d50 is subject to a tolerance of
+/- 2 cm (+/- 0.79 inch).
d50/d10 ratio ≥ 0.5
Residual lighting intensity with one
shade
92%
147,200 lux
Residual lighting intensity with two
shades
68%
108,800 lux
Residual lighting intensity with lens
barrel
98%
156,800 lux
Residual lighting intensity with lens
barrel and one shade
91%
145,600 lux
Residual lighting intensity with lens
barrel and two shades
66%
105,600 lux
Illumination depth (L1 + L2) at 20% Ec /
EN ISO 60601-2-41 2nd Edition
1930 mm/75.98 inch with ALC Plus
Illumination depth (L1 + L2) at 60% Ec /
EN ISO 60601-2-41 3rd Edition
1090 mm/42.91 inch with ALC Plus
Average service life of the LEDs > 60,000 hrs.
Color temperature 3,500 K, 4,000 K, 4,500 K, 5,000 K
Color rendition index Ra Max. 97
Color rendition index R9 Max. 96
Color rendition index R13 Max. 99
