Technical data
76
7990087_030_03 – 2080492 – 2023-01-19
12 Technical data
12.1 Surgical light accessories
12.2 Device data
Product designation Equipment
Sterile Light Control (SLC) Optional
Adaptive Light Control Plus (ALC Plus) Present
Automatic shade management (available for a maximum of
2 surgical lights on a single ceiling pipe)
Present
Dimensions
Height [A] 95.1 mm/ 3.74 inch
Height [B] 111.4 mm/ 4.39 inch
Width [C] 731.2 mm/ 28.79 inch
Width [D] 709.0 mm/ 27.91 inch
IP classification according to IEC 60529
Lamp head IP40
Support arm system
VALiA IP30
VISTA IP10
Mobile Control 7,9 with Catalyst Case iPad Mini 5
(#2074252, product from a third-party manufacturer)
IP54
Wall Control Panel IP42
Electrical data
Supply voltage at the power supply unit 100–240 V AC
50/60 Hz
Supply voltage to the 24 V converter 22–32 V DC
22–26 V AC
Maximum power consumption for a surgical light < 160 VA
Internal fuse (only mobile pedestal version) 2× T10 A
