Description
7990087_030_03 – 2080492 – 2023-01-19 21
4Description
iLED 7 surgical lights are available in the Single, Duo, Trio, Quad,
Mobile and Pendant variants with different boom lengths and
spring arms.
The Single, Duo, Trio, Quad and Pendant variants are ceiling-
mounted versions with support arms.
With the iLED 7 Ceiling Single/Duo/Trio/Quad variants, the light
head is attached to the ceiling in combination with a pre-assembly
set and a VidiaPort support arm system. Single, double, triple and
quadruple axes are available with S or C booms.
With the iLED 7 Pendant variant, the light head is attached to the
ceiling in combination with an FCS/TruPort support arm system.
The Mobile variant is a mobile single light with a spring arm.
With the support arm system and with the mobile variant with the
spring arm, the light head can be positioned as desired and
precisely pointed at the wound area.
The surgical light is operated with the control on the lamp head or
with a separate control module. The light system can be
individually adjusted with the following functions:
–Light field size
– Lighting intensity
– ALC Plus (Adaptive Light Control Plus)
– Color temperature
– Shadow management
– Synchronization (not for Mobile variant)
– Radio connection and safe mode (not for Mobile variant)
The surgical light emits infrared light. The infrared radiation of the
3D sensor can interfere with the infrared radiation of other devices
that communicate in the same wave length range. The essential
functions of the surgical light are, however, not affected by the
interference.
4.1 Overview of surgical light
4.1.1 iLED 7 Ceiling Trio surgical light system
The iLED 7 Ceiling Trio surgical light system (example shown
below) consists of the following components:
– the canopy [1]
– the ceiling conduit [2] (part of the Pre-Install Set iLED 7) and the
central axis [3]
– a horizontally rotating upper C boom [4] on the central axis with
a horizontally and vertically adjustable MD26+ spring arm [7]
(VidiaPort Springarm Top)
– a horizontally rotating middle S boom [5] on the central axis
with a horizontally and vertically adjustable L21 spring arm [8]
– a horizontally rotating lower S boom [6] on the central axis with
a horizontally and vertically adjustable LCH19 spring arm [9]
– a monitor mount (VidiaPort monitor Holder Single) [10] on the
upper boom for mounting a flat screen
