Description
7990087_030_03 – 2080492 – 2023-01-19 23
4.1.2 iLED 7 Ceiling Quad surgical light system
The iLED 7 Ceiling Quad surgical light system (example shown
below) consists of the following components:
– the canopy [1]
– the ceiling conduit [2] (part of the Pre-Install Set iLED 7) and the
central axis [3]
– a horizontally rotating upper C boom [4] on the central axis with
a horizontally and vertically adjustable MD26+ spring arm [7]
(VidiaPort Springarm Top)
– a horizontally rotating lower C boom [23] on the central axis
with a horizontally and vertically adjustable MD26+ spring arm
[7] (VidiaPort Springarm Middle)
– a horizontally rotating upper S boom [5] on the central axis with
a horizontally and vertically adjustable LCH19 spring arm [9]
– a horizontally rotating lower S boom [6] on the central axis with
a horizontally and vertically adjustable L21 spring arm [8]
– two monitor mounts (VidiaPort Monitor Holder Single) [10] on
the C booms for mounting a flat screen each
– two horizontally rotating and vertically adjustable light
heads [14]
[6] Lower S boom
[7] Spring arm
(MD26+)
[8] Spring arm
(L21)
[9] Low room height spring arm
(LCH19)
[10] Monitor mount
(VidiaPort Monitor Holder Single and VidiaPort Monitor
Holder Box)
[11] Flat screen
[12] iLED 7 comfort bracket
[13] 1/4 bracket iLED 7
[14] Lamp head
[15] Control element
The functions available on the control are limited.
[16] Handle adapter
(Adaption Standard handle/Adaption disposable handle)
[17] SLC Handle Adapter
[18] TruVidia wireless camera
[19] Mobile Control 7,9
[20] Wall Control Panel
[21] RS232 interface
[22] Sterilizable handle
(Sterilizable ALC Handle, 3 pcs/Sterilizable Central Handle,
3 pcs/Sterilizable Camera Handle, 3 pcs)
[34] Disposable handle adapters
(Handle sleeve flange type short/Handle sleeve flange type
middle/Handle sleeve flange type long/Handle sleeve ring
type short/Handle sleeve ring type long)
