Description
7990087_030_03 – 2080492 – 2023-01-19 25
4.1.3 iLED 7 Pendant surgical light system
The iLED 7 Pendant surgical light system (example shown below)
consists of the following components:
– the canopy [1]
– the FCS/TruPort ceiling-mounted supply unit [24] with a
Pendant Adapter [25]
– a horizontally rotating S boom [26] on the Pendant Adapter [25]
with a horizontally and vertically adjustable LCH19
spring arm [9]
– a rotating and vertically adjustable light head [14]
In the example, the iLED 7 Pendant surgical light system is
equipped with the following additional accessories of Baxter and
the following third-party products:
– an SLC handle adapter [17] or a TruVidia Wireless camera [18] or
a handle adapter [16]
– a sterilizable handle [22] for the TruVidia camera system [18] or
the SLC handle adapter [17] or the handle adapter [16]
[1] Canopy
[2] Ceiling conduit
[3] Central axis
[4] Upper C boom
[5] Upper S boom
[6] Lower S boom
[7] Spring arm
(MD26+)
[8] Spring arm
(L21)
[9] Low room height spring arm
(LCH19)
[10] Monitor mount
(VidiaPort Monitor Holder Single and VidiaPort Monitor
Holder Box)
[11] Flat screen
[12] iLED 7 comfort bracket
[13] 1/4 bracket iLED 7
[14] Lamp head
[15] Control element
The functions available on the control are limited.
[16] Handle adapter
(Adaption Standard handle/Adaption disposable handle)
[17] SLC Handle Adapter
[18] TruVidia wireless camera
[19] Mobile Control 7,9
[20] Wall Control Panel
[21] RS232 interface
[22] Sterilizable handle
(Sterilizable ALC Handle, 3 pcs/Sterilizable Central Handle,
3 pcs/Sterilizable Camera Handle, 3 pcs)
[23] Lower C boom
[34] Disposable handle adapters
(Handle sleeve flange type short/Handle sleeve flange type
middle/Handle sleeve flange type long/Handle sleeve ring
type short/Handle sleeve ring type long)
