10
Devices with integrated control unit PICO-troniX1 can be supplied with bayonet plug-type
connection Hirschmann plug-type connection connection plug 10 m longor . The and a
connectioncable areincluded inthe scopeof deliveryfor bothversions.
Devices with integrated control unit PICO-tronic are supplied with two Hirschmann plug-type
connections connection plug for the voltage connection 10 m long. The (see fig. 40) and a
connection cable connection plug for the additionalare included in the scope of delivery. The
equipment without connection cable(see fig. 40) is supplied . If you need a connection cable, it
hasto beordered (ordernumbers onrequest).separately
Thefollowing listedconnection diagramsare validfor standardversions.
Otherconnection diagramsmay bevalid forspecial versions.These areavailable onrequest.
6.2.1 Connectiondiagram fordevices withPICO-troniX1 andbayonet plug-typeconnection
Fig.1:
6.2.2 Connectiondiagram fordevices withPICO-troniX1 andHirschmann plug-typeconnection
Fig.2:
Notice!
+Ub
Mass
green
red
black
orange
brown
Push-button
for intermediate
lubrication
Lampe red
Lampe green
Mass
+Ub
brown
black
red
green
orange
Lamp red
Lamp green
Push-button for
intermediate lubrication
PIN 7
PIN 5
PIN 2
PIN 1
PIN 6
