8.4.2 Pumpelements PE-60F,PE-120 Fand PE-170F
The pump elements PE-60 F, PE-120 F and PE-170 F are intended for the use in progressive lubrication systems. The
delivery rate of these pump elements is set to 0,06 cm³/stroke ( PE-60 F), 0,12 cm³/stroke (PE-120 F) or 0,17 cm³/stroke
(PE-170 F) and cannot be adjusted. The pump elements are deliverable with different pipe connections and with or
withoutpressure limitingvalve (seefig. 25).
Fig.25:
withpressure limitingvalve withoutpressure limitingvalve
Eachtype ofpump elementhas itsown markingin ordertoenable avisual differentiation(see fig.26).
Fig.26:
PE-60F PE-120F PE-170F
additionalgroove withoutgroove additional groove
atdiameter Ø23,8 athexagonalAF 24
Pipe Ø6 = 27,5
Pipe Ø8 = 24,5
Pipe Ø10 = 25,5
Pipe connection
Ø6 / Ø8 / Ø10
AF 24
G 1/4
Ø10
approx. 46
AF 17
AF 19
AF 22
Ø6 - Ø10
Order no.: 04062395
Reducer unions
Ø8
approx. 48
AF 17
AF 17
AF 19
Ø6 - Ø8
Order no.: 04062999
approx. 84,9
AF 19
G 1/4
38
approx. 40
approx. 64
approx. 121
M20x1,5
AF 24
AF 19
approx. 54,9
16,5
AF 17
Pipe connection Ø6
Pressure limiting valve
(set to 290 bar)
USIT ring U 28x20,7x1,5
Connecting socket for
pressure gauge
Pipe Ø6 - G 1/4
Order no.: 04014816006
