7.4 Ventilationof thelubrication system
· Ventilatethe wholelubrication systemon firststart-up andafter eachlubricantchange!
· Ventilationis doneby operatingthe systemin pressurelesscondition andwithopen systemoutlets!
· Operatethe deviceuntil lubricantescapes fromthe pressureconnection withoutairinclusions.
8. Functional description
8.1 Lubricationsystems
The device can be used for the lubrication in progressive lubrication systems, multi-line lubrication systems or in mixed
lubrication systems. The lubrication systems are also controlled by the integrated control unit PICO-troniX1 or PICO-
tronic.
Up to two lubrication circuits, which are independent from each other, can be connected the device at installation into ato
progressivelubrication system.
Upto 8lube pointscan besupplied withlubricant whenthe deviceis usedin amulti-line lubricationsystem.
Bothsystems canalso becombined withthe device(mixed lubricationsystem).
8.1.1 Progressivelubrication systems
Progressivelubrication systemsare lubricationsystems whichcan processlubricants upto NLGI cl.2.
A progressive lubrication system mainly consist of a lubrication pump and one or several progressive distributors. Thes
lubrication pump supplies the lubricant into a main distributor. This distributor distributes the lubricant in the correct
relationto thesecondary distributors,which redistributethe lubricantto thelubepoints.
If one lube point does not take any lubricant from the distributor, it blocks. Pressure builds up in the system by this. The
system pressure is limited to 290 bar by a pressure limiting valve at the pump element (see fig. 19, pos. 11 and pos. 12).
Thesystem isthereby protectedfrom beingdamaged bytoo highpressure.
8.1.2 Multi-linelubrication systems
Multi-linelubrication systemsare lubricationsystem whichcan processlubricants upto NLGIcl. 2.s
A multi-line lubrication system mainly consists of a lubrication pump and several lubrication lines which are connected
directly to the lube points. Each lube point requires its own pump element atthe lubrication pump (see fig. 19, pos. 3 up to
pos.10).
8.1.3 Mixedlubrication systems
Aprogressive lubrication system and a multi-linelubrication system can be connected the device atthe same time; thisto
iscalled amixed lubricationsystem.
One lubrication circuit with progressive distributors can each be connected the pump elements pos. 1 and pos. 2 (seeto
fig.19). Onelube pointcan eachbe connected thepump elementspos. 3to pos.10 (seefig. 19).to
