8.2 Setupof thedevice
Thedevice mainlyconsists of6 assemblies(see fig.20).
Fig.20:
Reservoir cover
with ventilation
Reservoir
1,5 liter
with follow-up
piston
Reservoir
1,5 liter
with agitator
blade
Pump element
PE-120 FV
Pump housing
Protective housing with integrated
control unit PICO-troniX1 and
bayonet plug-type connection
Connection plug
Hirschmann 7-pole
Connection plug
bayonet 7-pole
Pump element
PE-5 to PE-50
Pump element
PE-60 to PE-170
Protective housing with integrated
control unit PICO-tronic and
2x Hirschmann plug-type connection
2x Connection plug
Hirschmann 7-pole
Protective housing with integrated
control unit PICO-troniX1 and
Hirschmann plug-type connection
