6.3.1 Disassemblyof apump element
A) Disconnectthe devicefrom thepower supply(pos. 1,see fig.5)and secureit againstrecommissioning.
Fig.5:
B) Unscrewthe pumpelement.
Fig.6:
Makesure thatthe pistonof thepump elementdoes notremain inthe pumphousing!
Ifthe pistonremains inthe pumphousing, theeccentric maybedamaged orthe devicemight block.
Caution!
1
AF 24
