6.3.2 Assemblyof apump element
C) Exchange the sealing, screw in the pump element and adjust it until the desired position has been reached.
Tightenthepump elementwith thebelow indicatedtightening torque(see fig.7).
Fig.7:
Tightenthepump elementsPE-5 toPE-50 witha tighteningtorque of20 Nm±10%.
Tighten the pump elements PE-60 F to PE-170 F and PE-120 FV with a tightening torque of
45Nm ±10%.
D) Reconnectthe deviceto thepower supply(pos. 1,see fig.8)
Fig.8:
Initiatea trialrun andlet thedevice operatewith openoutlets untilthe lubricantleaks outbubble-free.
