47
9.2.13 Specialfunction Cycle locked
With the special function , the function of the lubrication system can be easily locked by an external sensorCycle locked
(such as PLC or board computer). This special function is needed for lubrication systems which are to lubricate machine
orvehicle partsonly whenthese arein operation.
If the machine or vehicle parts are temporarily taken out of order, the cycle is locked. The green LED in the inspection
window of the protective housing (see fig. 40) starts to flash (see chapter 13.2 „Signal indicators of the integrated control
unitPICO-tronic").
If this casehappens during the lubrication duration, thelubrication is finished. Thecycle is locked afterwards.The cycle is
endednormally whenthe lockis lifted.
If th case happensoutside the lubrication duration, the cycleis stopped at this point.The cycle is continuedwhere i wasis t
interruptedwhen thelock islifted.
The special function is not displayed by the special functionCEycle locked xternal status signal
and cannot be selected at the same time as the special function Adjustment to operating
conditions.
9.2.14 ErrorLubrication deficit
Theerror occurswhen alubrication cannotbe finishedduring acycle sequence.In thiscase, thedeviceLubrication deficit
needs more time for processing the lubrication duration than there is time available by the length of the cycle duration. If
this case occurs in several cycles in a row, the integrated control unit an error (see chapter 13.2 „Signal indicatorsreports
of the integrated control unit PICO-tronic"). However, the integrated control unit does not switch off the device because a
lubricationdeficit isbetter thanno lubrication.
Theintegrated controlunit automaticallyresets theerror whena completelubricationis finishedwithin afollowing cycle.
10. Maintenance
Disconnectthe devicefrom powersupply before .maintenanceor repairs
Onlycarry out in and .maintenanceand repair complete devicestandstill pressurelesscondition
Check the surface temperature of the device to avoid the risk of burns by radiant heat. Wear heat-resistant
gloves and safety goggles! Clean soiled or contaminated surfaces before maintenance, wearing protective
equipmentif necessary!Secure thedevice againstrecommissioning duringmaintenance andrepairwork!
10.1 Generalmaintenance
· Retightenall fittings6 weeksafter startup!
· Checkall componentsfor leakagesand damageat leastevery fourweeks!
If leakages are not repaired, lubricant . Remove possible puddles ofmight escape under high pressure
lubricantimmediately.
Notice!
