6.3 Assemblyof thepump elements
Differentpump elementscanbe installedinto thedevice (seechapter 8.4„Pump elements“).
Fig.4:
Thepump elementsPE-60 F, PE-120F,PE-170 Fand PE-120FV canbe screwedinto theoutlets 4and 10(see fig.4).
Thepump elementsPE-5, PE-10,PE-15, PE-25and PE-50canbe screwedinto theoutlets 1to 3and 5to9 (seefig. 4).
Remove the screw plug with an Allen key AF 10 (outlets 4 and 10, see fig. 4) or AF 6 (outlets 1 to 3 and 5 to 9, see fig. 4)
fromthe outletinto whichyou wantto screwin thepump element.
Exchangethe sealingof thepump elementin orderto avoidthatdamaged sealingsare reused.
When the pump elements PE-5 to PE-50 are ordered separately, the sealing is not included in the
scope of delivery and has to be ordered separately if needed (see chapter 8.4.5 „Code of the pump
elementsfor multi-linelubrication systems“).
Inthe following,the disassemblyand assemblyof thepump elementsisdescribed atthe examplePE-120 F.
Notice!
1
2
3
4
5
10
6
7
8
9
