7.2.1 Initialfilling ofdevices withfollow-up piston
Use a standard grease pump (hand lever grease gun) for the initial filling of the device with follow-up piston and fill the
devicevia thecone-type zerk.
Pay attentionto utmost cleanliness at theinitial filling ofthe device. Onlyfill in clean lubricant. When
dirt particles get into the device, the pistons of the pump elements can wear, which results in the
destruction ofthe pumpelements.The dirtparticles canalso getinto the lubrication system andcan
cloglines orconnected progressivedistributors.
A) Connect the device according to the connection diagram (see chapter 6.2 „Power connection“) and turn itaround
sothat thereservoir coverpoints down(see fig.9).
Fig.9:
B) Removethe overfillprotection andthe protectivecap ofthe cone-typezerk(see fig.10).
Fig.10:
Caution!
Overfill protection
Cone-type zerk with
protective cap
Overfill protection removed!
Protective cap removed!
