© BEKA 201 !9 All rights reserved
BAL2185_Grease_lubrication_pump_PICO_with_PICO-troniX1_-tronic_0519EN 10158410
...a product of
57
15. Dimensionaldrawing
15.1 Dimensionaldrawing fordevices withintegrated controlunit PICO-troniX1
Fig.58:
Ø128
approx. 42
approx. 1873539
approx. 261
Ø9,5
approx. 242
76
approx. 111
150
approx. 171
80
approx. 148
approx. 132approx. 156
approx. 135
View of a device
with bayonet
plug-type connection
View of a device
with Hirschmann
plug-type connection
approx. 127
