BEKA BEKA-MAX PICO-troniX1 User Manual

BAL2185_Grease_lubrication_pump_PICO_with_PICO-troniX1_-tronic_0519EN 10158410
...a product of
© BEKA 201 All !9 rights reserved
54
13.1 Signalindicators ofthe integratedcontrol unitPICO-troniX1
The functions ofthe device are displayedvia two LEDs (greenand red) in the inspection window of the protectivehousing
(seefig. 36),whereby thered LEDalways displaysan errorin theprogram sequence.
The functions ofthe device can alsobe displayed by externally installedsignal lamps. However, these haveto be ordered
separately(order numberon request).
Ifseveral errorsoccur atthe sametime, theyare displayedoneafter theother witha breakof approx.2 seconds.
Signal indicators
Function
Operable: 1.5 s
ON
ON
OFF
OFF
LED red
LED green
Indication of the operational
capability after switching on the
voltage for the first time
During the whole lubrication
ON
ON
OFF
OFF
LED red
LED green
Sequence of a lubrication
Error Lubrication deficit
ON
ON
OFF
OFF
LED red
LED green
1 s 1 s
1 s
1 s
Revolution error in operational mode
of revolution-dependent lubrication
duration
Error Level too low
(only for devices with follow-up
piston)
ON
ON
OFF
OFF
LED red
LED green
1 s
1 s
Trial lubrication (permanent
lubrication) In order to initiate a;
permanent lubrication for service
purposes in the operational mode of
time-dependent lubrication duration,
the lubrication duration has to be set
higher than the cycle duration.
ON
OFF
LED red
ON
OFF
LED green
1 s
1 s
Until lubricant is refilled
ON
OFF
LED red
ON
OFF
LED green
