The component (e.g. relay or lamp) for the evaluation of the signals can be connected to the integrated control unit at the
left Hirschmann plug-type connection on the protective housing (GO610WF, see fig. 40). The component and the
connectioncable etc.are notincluded inthe scopeof delivery.
Bydefault settingerror signal,the integratedcontrol unitis deliveredwith the .
If the is required, it can bedirectly or canbe changed using the diagnosis softwaresetting OK-signal indicated at order
BEKA-DiSys www.beka-lube.de(withthe currentversion availableat ).
9.2.12 Specialfunction Adjustment to operating conditions
An adjustment to the operating conditions can be done via a 3-notch switch (see fig. 50)
withinthe first30 secondsafter switchingon thevoltage.
The 3-notch switch is not included in the scope of delivery, however, it can be ordered
separately(order no.:1000950018).
Operatingconditions:
Normal- Thelubepoints receivelubricant inthe setinterval ata normalload(see fig.51).
Fig.51:
Light- Thelubepoints receivelubricant inextended intervalsat alight load(seefig. 52).
Fig.52:
Heavyduty -Thelube pointsreceive lubricantin shorterintervals ata highload(see fig.53).
Fig.53:
After operating the 3-notch switch, either the voltage (ignition) has to be switched off and on again or an intermediate
lubricationhas tobe triggeredat thepush-button forintermediate lubrication(seefig. 40).
The specialfunction cannot beselected at thesame timeAdjustment to operating conditions as
thespecial function .Cycle locked
Fig. 50:
Cycle duration 100%
e. g. 2 h
Lubrication duration
Notice!
Cycle duration 125%
e. g. 2,5 h
Lubrication duration
Cycle duration 75%
e. g. 1,5 h
Lubrication duration
