13.2 Signalindicators ofthe integratedcontrol unitPICO-tronic
The functions ofthe device are displayedvia two LEDs (greenand red) in the inspection window of the protectivehousing
(seefig. 40),whereby thered LEDalways displaysan errorin theprogram sequence.
The functions ofthe device can alsobe displayed by externally installedsignal lamps. However, these haveto be ordered
separately(order numberon request).
Ifseveral errorsoccur atthe sametime, theyare displayedoneafter theother witha breakof approx.2 seconds.
Signal indicators Function
Operable: 1.5 s
ON
ON
OFF
OFF
LED red
LED green
Indication of the operational
capability after switching on the
voltage for the first time
During the whole lubrication
ON
ON
OFF
OFF
LED red
LED green
Sequence of a lubrication
Cycle locked
(is not displayed via the special
function )External status signal
Pulse error in operational mode of
pulse-dependent cycle duration
Error Line break
ON
ON
OFF
OFF
LED red
LED green
1 s
1 s
ON
ON
OFF
OFF
LED red
LED green
1 s
1 s 1 s
1 s
Pulse error in operational mode of
pulse-dependent lubrication duration
ON
ON
OFF
OFF
LED red
LED green
1 s
1 s
ON
ON
OFF
OFF
LED red
LED green
1 s
1 s
1 s
1 s1 s
