© BEKA 201 !9 All rights reserved
BAL2185_Grease_lubrication_pump_PICO_with_PICO-troniX1_-tronic_0519EN 10158410
...a product of
19
C) Fillingvia thefilling setPICO Fill
The filling set PICO Fill (order no.: 208103027) has been developed for an easy and quick filling of the device. It consists
ofa fillingconnection M20x1,5(order no.:21520152) anda fillinggun(order no.:208103026).
Remove the screw plug from the outlet 4 or 10 (see fig. 4 in chapter 6.3 „Assembly of the pump elements“) and screw in
thefilling connectionM20x1,5.
Operatethe fillinggun untilthe lubricantleaks outvisibly attheoutlet (approx.10 mm,see fig.17).
Connectthe fillinggu thefilling connectionM20x1,5 and fillthe deviceup tothe maximumlevel.nto
Remove the filling connection M20x1,5 after finishing the filling process and screw the screw plug, which had been
removedearlier, backin.
Fig.17:
7.3 Checkof rotationaldirection ofthe device
· Compare the rotational direction of the agitator blade with the directional arrow on the level sticker (see fig. 18) for
deviceswith agitatorblade.
· Checkthe electricalconnections ofthe deviceat awrong rotationaldirectionand changethese ifnecessary.
The and the will be when they are operated in themotor damaged wrong rotationaldevice
directionfor alonger time!
Fig.18:
Level max.
10 mm
Lubricant
Filling gun
Caution!
Directional arrow
on level sticker
