9. Integrated control unit
Progressive lubrication systems, multi-line lubrication systems and mixed lubrication systems can be controlled with the
controlunit PICO-troniX1or PICO-tronicwhich isintegrated inthe device.
Theintegrated controlunit PICO-troniX1or PICO-tronicoperates dependentfrom thelubrication cycle.
A lubrication cycle consists of the cycle duration and the lubrication duration (pump operating time) which is included in
the cycle duration. Cycle duration means the period from the beginning of a lubrication to the beginning of the next
lubrication(see fig.35).
Fig.35:
9.1 PICO-troniX1
The is determined forthe integratedcontrol unit PICO-troniX1.cycleduration time-dependently
The can bedetermined or .lubricationduration time- revolution-dependently
Functions:
Thefollowing functionscan beevaluated withthe integratedcontrol unit:
· Levelmonitoring (onlyfor deviceswith follow-uppiston, seechapter 8.6„Levelmonitoring“)
Signalindicators:
The followingmessages are displayed bythe integrated controlunit by the red and green LEDin the inspectionwindow of
theprotective housing(see chapter13.1 „Signalindicators ofthe integratedcontrolunit PICO-troniX1"):
· Operationalcapability
· Lubricationin process
· Reservoirempty (onlyfor deviceswith follow-uppiston)
· Setnumber ofpump revolutionshas notbeen reachedwithin themonitoring timeof revolutions
· CPU/ memorydefective
· Trial lubricationin process
Operationaldatabase:
Theintegrated controlunit hasan operationaldatabase inwhich thefollowingvalues arestored:
· Dataof thecontrol unit(type, version,serial number, manufacturingdate)
· Currentsettings (cycleduration, operationalmode ofthe lubricationduration, lubricationduration,monitoring times)
· Statistical values (operating hours, operating time of the device, number of the intermediate lubrications, number of
thelevel errors,number ofthe revolutionerrors, numberof theoveralldiagnoses etc.)
· Dateand timeof thelast diagnosis
The operational mode of the lubrication duration, the setting ranges of the cycle and lubrication
duration and the setting of the monitoring time can be changed at any time using the diagnosis
software (withthe currentversion availableat ).BEKA-DiSys www.beka-lube.de
Notice!
Lubrication duraction
Cycle duration
Lubrication cycle
