43
9.2.5 Operationalmode oftime-dependent lubricationduration
At theoperational mode oftime-dependent lubrication duration, thelubrication duration canbe set inminutes or seconds,
depending on the selected setting range. The setting range can be changed using the diagnosis software BEKA-DiSys
(withthe currentversion availableat ).www.beka-lube.de
Fig.44:
Settingranges ofthe time-dependentlubrication duration:
· 1to 16min (16notches à1 min)
· 2to 32min (16notches à2 min)
· 2to 32s (16notches à2 s)
The time-dependent lubrication duration can be set (within a setting range) using the left grid switch in the inspection
windowof theprotective housing(see fig.40).
9.2.6 Operationalmode ofpulse-dependent lubricationduration
At the operational mode of pulse-dependent lubrication duration, the lubrication
duration is determined by the number of incoming pulses of a sensor (e.g. proximity
switch at a progressive distributor, see fig. 45). If the integrated control unit receives
no pulse signal within the adjustable pulse monitoring time of lubrication duration
(standard setting 12 min), it displays an error (see chapter 13.2 „Signal indicators of
theintegrated controlunit PICO-tronic").
When the cause of error has been eliminated, the error has to be reset by pushing the
push-buttonfor intermediatelubrication (seefig. 40).
The sensor can be connected to the integrated control unit at the left Hirschmann
plug-typeconnection onthe protectivehousing (GO610WF, seefig. 40).
The setting range and the pulse monitoring time of lubrication duration can be changed using the diagnosis software
BEKA-DiSys www.beka-lube.de(withthe currentversion availableat ).
Fig.46:
Settingranges ofthe pulse-dependentlubrication duration:
· 1to 16pulses (16notches à1 pulse)
· 17to 32pulses (16notches à1 pulse)
· 33to 48pulses (16notches à1 pulse)
The pulse-dependent lubrication duration can be set (within a setting range) using the left grid switch in the inspection
windowof theprotective housing(see fig.40).
Time-dependent
lubrication duration
Cycle duration
Fig. 45:
Pulse signals
Cycle duration
Pulse-dependent
lubrication duration
