8 Parts
This chapter lists the exploded views and material codes of the parts including the monitor's main unit, SMR and
parameter module. It helps the engineer to identify the parts during disassembly of the patient monitor and spare parts
replacement.
8.1 N17/M17/N15/M15/N12/M12 Whole Unit
8.1.1 Exploded View
8.1.2 Parts List
No. Order Number Part Description Qty Remark
1 / Front Housing view 1
/
2 / Rear Housing view 1
/
3 / Bottom Housing view 1 /
②
①
③
To Next Page
