7.5.8 Removing the Independent Display Board Assembly (N17/M17 Series)
1. First screw out the two DVI stud screws.
2. Remove the independent display board connection line and the internal module rack connection line, loosen and
remove the four M3X6 screws, and then take out the independent display board assembly.
3. Loosen and remove the four M3X6 screws, and take down the independent display board.
