4-21
1. Connect and set the patient monitor and Vigilance monitor per the procedures in the Operator's Manual.
2. Set the Vigilance monitor to Demo mode. Start the CCO and SvO
2
tests in Demo mode.
3. Verify that the CCO/SvO
2
numerics displayed on the patient monitor and Vigilance monitor are consistent.
Output Performance
Tools required:
Multimeter
1. Connect the signal output end of the connecting cables of the CCO/SvO
2
module to the oscilloscope.
2. Select
CCO Setup→Signal Output Setup and then select Simulated High Value from the pop-up menu. Check
that the amplitude of electrical level at the signal output port of ECG, MAP, CVP and SpO
2
are 5±0.015 V, 5±0.25 V,
5±0.25 V and 10±0.5 V respectively.
4.4.15 PiCCO Test
Performance Test
Tools required:
 Medsim300B patient simulator or Prosim 8
 PiCCO IBP test cable (PN: 040-001300-00)
1. Connect the patient simulator, the PiCCO IBP test cable and the PiCCO module.
2. Let the patient simulator outputs 0 mmHg respectively to the pArt channel and the pCVP channel.
3. Select the pArt parameter interface to access the pArt Setup menu, and then select Zero.
4. Select the pCVP parameter interface to access the pCVP Setup menu, and then select Zero.
5. Let the patient simulator output static pressure 200 mmHg to pArt channel and 20 mmHg to pCVP channel.
6. The pArt value displayed on the monitor should be within 200±4 mmHg, and pCVP value within 20±1 mmHg.
7. If the pArt error is beyond ±4 mmHg or pCVP error beyond ±1 mmHg, calibrate the PiCCO module. If the module
was calibrated with a dedicated reusable IBP sensor, check the calibration together with this IBP sensor.
8. Let the patient simulator output ART signal to the pArt channel and CVP signal to the pCVP channel, check whether
the IBP waveform is correctly displayed.
Pressure Calibration
Method 1:
Tools required:
 Medsim300B patient simulator or Prosim 8
 PiCCO IBP test cable (PN: 040-001300-00)
