Bernina B 570 - Section 6 - Adjustments

BERNINA International AG Seestrasse 161 CH-8266 Steckborn Schweiz Seite 143 von 172
DRAFT – VERSION
6.6 Section 6 – Adjustments
6a
Sewing-off (user interface)
6b Electronic balance calibration
6c Buttonhole calibration
6d Thread cutter clamping mechanism (solenoid)
6e Thread cutting
6f Resetting upper-thread tension to default
6g Resetting to factory settings (Reset all)
6h Presser foot height
6j Automatic upper-thread tension
6k Test Tie On
6l Start-/Stop slide (SSU) calibration
6m Normal SSU stitching speed
6n BSR sewing mode
6o Magnetic position encoder calibration
Adjustments on the second page are for Production only.
They are for information only:
6r Weight difference measuring
6sUpper-thread tension calibration
6t Number pad
6a Sewing-off (user interface)
Is used to go to sewing interface
Check:
• Select test 6a.
• Press the eye icon in the right box to switch the upper-
thread sensor off.
• Press the yellow icon to access sewing mode.
• The machine can now be sewn off using various stitch
patterns.
• Press to exit sewing mode.
Note:
Ensure to carry out all crucial adjustments and calibrations
by following the check list in section 11.
Important!
Do not run a threaded machine without fabric!
