Bernina B 570 - Needle Height

BERNINA International AG Seestrasse 161 CH-8266 Steckborn Schweiz Seite 99 von 172
DRAFT – VERSION
5.5.5 Needle height
Check:
• Remove needle.
• Attach distance gauge a (030883.50.03 silver-coloured with 3 punctures).
• Lower the feed-dog.
• Select ‘centre’ needle position.
• Switch machine off if required.
• Place distance plate b (730475.51.00) under distance gauge a on stitch plate.
• Needle bar BDC represents 'target’ c on distance plate b level 2.
Note:
If the position of the gauge b deviates from value c = 2, the needle stop pin must be replaced. This applies to
all 5Series machines with basting device (VIO).
Adjustment:
• Remove distance gauge a.
• Remove needle clamp (see 4.3.15
)
• Replacing the needle stop pin d (T6) allows for modification of the height.
• Needle stop pins are available in 8 different diameters (see table).
• Select the appropriate needle stop pin d to correct any deviation from the target.
• Refit needle clamp (see 4.2.15
).
Note:
• The height difference between levels corresponds to the diameter difference of the next larger or
smaller needle stop pin d.
• If the needle requires lifting = use smaller diameter.
• If the needle requires lowering = use larger diameter.
Available sizes of needle stop pins
No.
Item no.
Height in mm
labelled
1
036687.50.00
2.2
n.a.
2
036687.50.01
2.4
n.a.
3
036687.50.02
2.6
n.a.
4
036687.50.03
2.8
n.a.
5
036687.50.04
3.0
n.a.
6
036687.50.05
3.2
n.a.
7
036687.50.06
3.4
n.a.
8
036687.50.07
3.6
n.a.
