Binder KBF P 240 - Chamber Overview; Instrument Panel

KBF P + KBF LQC + KBWF (E6) 11/2016 page 19/189
2.2 Chamber overview
Figure 4: Constant climate chamber / Growth chamber size 240
(A) Instrument box
(B) Door handle
(C) Outer door
(D) Refrigerating machine and humidity generation module
2.3 Instrument panel
5,7" controller display with touchscreen
USB interface
Pilot lamp
Figure 5: Instrument panel with MB2 program controller and USB interface
(A)
(B)
(C)
(D)
