KBF P + KBF LQC + KBWF (E6) 11/2016 page 153/189
21.9.2 Mounting the wastewater can
(1) Fixing (if required)
Hang the can with its holding device on its 4 carriers at the free space next to the freshwater can.
(2) Hose connections
Plug the wastewater hose to the hose connection (17) of the wastewater can and secure it with a
hose clamp. You can use a part of the standard supplied water hose.
Hose connection of the wastewater can (17)
Figure 39: Wastewater can (option)
Plug the free hose edge to the wastewater connection “OUT” (14) at the rear of the chamber and
secure it with a hose clamp.
You can remove the wastewater can with its holding device for emptying (disconnect the hose first before
emptying).
CAUTION
Overflow of the wastewater can.
Damage to the surrounding.
Empty the wastewater can in a timely manner before it is full.
Bringing a source of humidity into the inner chamber may increase wastewater production.
Regularly check the filling level of the wastewater can.
